Product feature of the LA-CC-04K05B
- High-resolution support: Supports up to 4K color image capture, can accurately capture subtle details, and is suitable for application scenarios with extremely high image quality requirements, such as precision electronic inspection, automated assembly line quality control, etc.
- Excellent optical performance: The lens uses high-end optical components and advanced coating technology to effectively reduce reflections and chromatic aberrations, ensure image clarity and color accuracy, and is suitable for industrial inspection tasks with strict image quality requirements.
- Multiple interface support: It has a variety of standard interfaces and is compatible with various machine vision systems. Common interface types include C-mount, which ensures its wide adaptability in different devices.
- Compact design: The compact design is suitable for installation in limited space. Even in narrow industrial environments, it can be easily integrated into automated production lines.
- Durability and reliability: The lens has high durability and stability, and can work stably in harsh industrial environments such as high temperature and humidity, ensuring long-term reliability.
CS Series LA-CC-04K05B Product Parameters
|
model |
LA-CC-04K05B |
|
brand |
Teledyne DALSA |
|
Resolution |
4096×2 |
|
Line frequency (kHz) |
48 |
|
Sensor type |
CMOS |
|
Line count |
2 |
|
Pixel size |
7.04μm |
|
Spectrum |
color |
|
Optical interface |
M42 |
|
Dynamic range |
60 dB |
|
Data interface |
CameraLink |
|
Power supply requirements |
8 W(12 ~ 24 VDC) |
|
Operating temperature |
0°C ~ +65°C(Front panel) |
|
Mechanical dimensions (W×H×L) |
62 mm × 62 mm × 37 mm |
|
Weight |
190 g |
Product application of the LA-CC-04K05B
- Industrial visual inspection: used in precise automated inspection systems to ensure quality control of production lines, such as parts inspection, welding inspection, etc.
- Automated production lines: provide accurate image data support for tasks such as material inspection and position correction in high-speed production environments.
- Robotic vision: integrated into the robot vision system to support robot automatic identification and grasping, position calibration and other operations.
- Medical imaging and biological detection: used for high-precision medical image analysis and image acquisition in biological experimental equipment.
Dimension
Product advantages
- Easy to install: Standardized installation method, suitable for various types of industrial cameras, the installation process is simple and convenient.
- Simple adjustment method: Users can adjust the focal length and aperture according to actual needs, optimize the imaging effect, and adapt to different working scenarios.
