ML-HM-16K30H
The ML-HM-16K30H is a high-performance, high-speed multi-line scan digital camera with top performance. It uses an advanced CMOS global shutter sensor with 16K resolution and a scan speed of up to 300 kHz, designed to meet the needs of industrial inspection in high-resolution and high-speed scenes. This camera excels in image clarity, dynamic range and data transmission efficiency, making it an ideal choice for complex inspection tasks.
ML-HM-16K30H Product Parameters
|
Model |
ML-HM-16K30H |
|
Brand |
Teledyne DALSA |
|
Resolution |
16384×4 |
|
Line frequency (kHz) |
300 |
|
Sensor type |
CMOS |
|
Line count |
4 |
|
Pixel size |
5μm |
|
Spectrum |
black and white |
|
Optical interface |
M90 |
|
Dynamic range |
72 dB |
|
Data interface |
CameraLink HS,CX4 AOC |
|
Power supply requirements |
25 W(12 ~ 24 VDC) |
|
Operating temperature |
0°C ~ +65°C(Front panel) |
|
Mechanical dimensions (W×H×L) |
97 mm × 140.5 mm × 78.6 mm |
|
Weight |
1200 g |
Product feature of the ML-HM-16K30H
- Ultra-high resolution
Equipped with a 16K (16384*4 pixels) ultra-high resolution sensor, it can capture the smallest details and is suitable for industrial inspection tasks that require extremely high image quality.
- Ultra-high-speed scanning
Supports scanning speeds up to 300 kHz, enabling real-time inspection even in extremely high-speed production lines, improving production efficiency.
- High dynamic range (HDR)
Can still output clear images in complex lighting environments, support multi-level grayscale expression, and ensure the accuracy and stability of inspection.
- High-bandwidth data interface
Equipped with CameraLink HS, CX4 AOC high-speed interface, supports real-time, high-speed data transmission, and is suitable for industrial automation scenarios that require fast response.
- Flexible compatibility
Supports standard M90 lens interface, and can select suitable industrial lenses according to needs to adapt to a variety of application scenarios.
- Rugged and reliable industrial design
The housing is made of high-strength metal material, which is resistant to vibration and impact, and is suitable for harsh industrial environments.
Product application of the ML-HM-16K30H
- Printing quality control
Detect color consistency, pattern alignment and text clarity of printed products to ensure high-resolution printing effects.
- Textile industry testing
Applicable to fabric and fabric defect identification, such as broken threads, uneven fibers, etc., to ensure textile quality.
- High-speed barcode and logo detection
Can quickly scan and analyze high-density barcodes, QR codes, etc., suitable for logistics packaging and sorting systems.
- Automobile and mechanical parts testing
Detect surface defects, dimensional accuracy and assembly quality of parts to ensure accurate manufacturing processes.
Dimension
