HL-FM-04K30H
HL-FM-04K30H is a high-speed, high-sensitivity TDI digital line scan camera with 4K resolution and a scanning speed of up to 300 kHz. It combines a global shutter CMOS sensor and high dynamic range imaging technology, designed for high-speed and high-precision scene detection. design. Its remarkable performance, robust industrial design and flexible interfaces make it excellent in industrial automation, surface inspection and high-resolution imaging applications.
HL-FM-04K30H Product Parameters
|
Model |
HL-FM-04K30H |
|
Brand |
Teledyne DALSA |
|
Resolution |
4096×(128+64) |
|
Line frequency (kHz) |
300 |
|
Sensor type |
CMOS |
|
Line count |
128 |
|
Pixel size |
5μm |
|
Spectrum |
black and white |
|
Optical interface |
M58 |
|
Dynamic range |
70 dB |
|
Data interface |
CameraLink HS,Fiber Optic |
|
Power supply requirements |
17 W(12 ~ 24 VDC) |
|
Operating temperature |
0°C ~ +65°C(Front panel) |
|
Mechanical dimensions (W×H×L) |
76 mm × 76 mm × 85 mm |
|
Weight |
500 g |
Product feature of the HL-FM-04K30H
- 4K high-resolution imaging
Provides clear imaging capabilities of 4096 pixels to capture tiny details, suitable for high-precision inspection tasks.
- High-speed scanning capability
The maximum scanning frequency reaches 300 kHz, supporting real-time imaging of fast-moving objects to meet the inspection needs of high-speed production lines.
- High dynamic range (HDR) support
Supports high sensitivity and high dynamic range to ensure the clarity and accuracy of output images in scenes with complex lighting conditions or strong contrast.
- High-bandwidth interface
Supports CoaXPress interface to achieve high-speed and stable data transmission, and adapts to a variety of industrial automation equipment.
- Flexible compatibility
Supports standard lens interfaces (F-mount or C-mount), providing a variety of lens options to meet the needs of different scenarios.
- Excellent cost performance
While providing leading performance in similar products, it optimizes costs and is a highly competitive industrial camera.
Product application of the HL-FM-04K30H
- Electronics manufacturing
Used for circuit board inspection, solder joint quality monitoring, component identification and precise measurement.
- Automobile manufacturing
Parts appearance defect detection, assembly line precision calibration, automated assembly verification.
- Food and pharmaceutical industry
Packaging integrity detection, label identification and content verification, production line foreign body detection.
- Scientific research and education
Used for experimental data acquisition, cell imaging analysis, dynamic experimental observation.
Dimension
After-sales service and maintenance
- Professional technical support
Remote technical guidance and problem solving.
Provide on-site installation and debugging services to ensure that the customer system is quickly put into operation.
- Customized solutions
Cameras and accessories with specific parameters can be customized according to industry needs to meet specific scene applications.
