AX-FM-04B12H

Built on Teledyne DALSA industry-leading CMOS line array sensors, the newly launched AxCIS series delivers highly integrated vision solutions while reducing system costs for demanding machine vision applications.

The AX-FM-04B12H combines a sensor, lens, and light source into a compact, user-friendly design, simplifying deployment and integration. Featuring the next-generation CLHS fiber optic interface, it ensures high-speed, long-distance data transmission with exceptional reliability, making it ideal for applications requiring high performance and scalability.

• Ultra-fast imaging with a 120 kHz line rate and high-resolution 900 dpi, ensuring exceptional detail and precision.
• True pixel integrity with no missing or interpolated pixels, delivering accurate and reliable image data.
• Advanced exposure control for optimal image quality across varying lighting conditions.
• Mono and HDR modes to accommodate both standard and high dynamic range imaging needs.
• Precalibrated pixel size, specifically designed for metrology applications, ensuring precise measurements.
• Next-generation Camera Link HS fiber interface, offering high-speed, long-distance data transmission with robust performance.

• Battery Inspection

It detects surface defects, internal structural inconsistencies, electrode misalignment, and coating irregularities in lithium-ion and other types of batteries.

• Print Inspection

The product performs real-time monitoring to detect misprints, ink smudges, alignment issues, and color inconsistencies, maintaining precise registration and print clarity.

• Printed Circuit Board (PCB) Inspection

Its high-speed imaging and HDR mode allow for detailed inspection, even on highly reflective or densely packed circuit boards, ensuring quality in automotive, aerospace, and consumer electronics industries.

• Web Inspection

This product's high-speed scanning and wide dynamic range enable manufacturers to detect and correct defects in real time, minimizing material waste and production downtime.

• General Purpose Machine Vision

It can be integrated into assembly lines, robotic vision systems, and precision measurement applications, ensuring high efficiency, accurate defect detection, and improved production yield across various industries.

• Hardware installation guidance:

Guide customers to complete the installation of the camera, including mechanical fixation, line layout, interface connection, etc.

• Software debugging:

Provide installation support for camera drivers and software platforms.

Assist in configuring parameters such as exposure, gain, frame rate, etc. to ensure the best effect of the camera in actual application.

Interface with the customer's host computer software system to ensure smooth data acquisition and processing.
