Gocator 2550

• High-Speed Scanning:

The Gocator 2550 can capture 10,000 contours per second, enabling high-speed, real-time 3D measurements with exceptional accuracy. This makes it perfect for high-throughput applications in fast-paced production environments.

• Large Field of View:

The sensor offers a maximum field of view of 518mm, providing a wide scanning area that ensures the complete coverage of large targets or components, reducing scanning time and improving efficiency.

• High-Resolution Imaging:

With an X-direction resolution of 80 μm, the Gocator 2550 delivers high-precision measurements capable of detecting even the smallest surface details and imperfections.

• Precise Z-Direction Repeatability:

The sensor achieves an impressive Z-direction repeatability of 2.0 μm, ensuring consistent, reliable measurements for accurate 3D profiling and inspection, even on complex or intricate parts.

• Easy Setup and Control:

The Gocator 2550 is designed for easy integration and control through a web browser or SDK, enabling streamlined setup without the need for additional software installation or complex programming.

• Built-in Measuring Tools:

This sensor comes equipped with pre-configured measuring tools, eliminating the need for manual programming and reducing the setup time, making it ready for use out of the box.

• EV Battery Manufacturing: Accurately measure the dimensions and surface features of EV battery components to ensure quality and precision.
• Consumer Electronics: Inspect electronic parts such as connectors and circuit boards for defects or dimensional inconsistencies.
• Automotive & Rail Industries: Scan materials like hot-rolled steel rails for structural integrity and defect detection.
• Rubber Tire Inspection: Effectively measure low-contrast materials, such as black rubber tires, with high precision.

Hardware installation guidance:

Guide customers to complete the installation of the camera, including mechanical fixation, line layout, interface connection, etc.

Software debugging:

• Provide installation support for camera drivers and software platforms.
• Assist in configuring parameters such as exposure, gain, frame rate, etc. to ensure the best effect of the camera in actual application.
• Interface with the customer's host computer software system to ensure smooth data acquisition and processing.
